Boiler Systems

our products - your solution

Your benefits by KOHLBACH

Long operating life

Exemplary high efficiency

Low maintenance

Extended full-load runtimes between maintenance shut-downs due to large heating surfaces reserves

The boiler systems form the heart of every biomass system.

Here Kohlbach offers a complete range of flexible industrial process heat applications: Warm/hot water, steam and thermal oil boiler plants assure a reliable and efficient supply of heat from 400 to 15,000 kW per module or with heat and electrical power, from approx. 3,000 kW thermal per module.

Warm water boiler

Boiler thermal output: 0,4 - 17 MW

2-path and 3-path boiler systems.

Parameters

Safety temperature (°C): 110

Operating parameters (°C): 100/80

The boiler systems form the heart of every biomass system.

Designed, constructed and tested in accordance with: Designed, constructed and tested in accordance with: EC directive 97/23/EC (Pressure Equipment Directive) whilst employing the following technical specifications: TRD regulations [German technical regulations for steam boilers], AD bulletins [pressure vessels workgroup], EN 287, EN 288, etc, monitoring of the quality assurance system through TÜV-Management Service GmbH, South German TÜV corporate group.

Hot water boiler

Boiler thermal output: 0,4 - 17 MW

2-path boiler systems.

Parameters

Safety temperature (°C): 160

Operating parameters (°C): 130/100

The boiler systems form the heart of every biomass system.

Designed, constructed and tested in accordance with: Designed, constructed and tested in accordance with: EC directive 97/23/EC (Pressure Equipment Directive) whilst employing the following technical specifications: TRD regulations [German technical regulations for steam boilers], AD bulletins [pressure vessels workgroup], EN 287, EN 288, etc, monitoring of the quality assurance system through TÜV-Management Service GmbH, South German TÜV corporate group.

Saturated steam boiler

Boiler thermal output: 0,8 - 12 MW

2-path boiler systems.

Parameters

Maximum pressure (bar): 30

Operating pressure (bar): 25

Feed water temperature (°C): 103

The boiler systems form the heart of every biomass system.

Designed, constructed and tested in accordance with: Designed, constructed and tested in accordance with: EC directive 97/23/EC (Pressure Equipment Directive) whilst employing the following technical specifications: TRD regulations [German technical regulations for steam boilers], AD bulletins [pressure vessels workgroup], EN 287, EN 288, etc, monitoring of the quality assurance system through TÜV-Management Service GmbH, South German TÜV corporate group.

Superheated steam boiler (fire tube)

Boiler thermal output: 3 - 12 MW

Parameters

Safety pressure (bar): 24,5

Safety temperature (°C): 350

Operating pressure (bar): 21,5

Operating temperature (°C): 300

Feed water temperature (°C): 103

The boiler systems form the heart of every biomass system.

Designed, constructed and tested in accordance with: Designed, constructed and tested in accordance with: EC directive 97/23/EC (Pressure Equipment Directive) whilst employing the following technical specifications: TRD regulations [German technical regulations for steam boilers], AD bulletins [pressure vessels workgroup], EN 287, EN 288, etc, monitoring of the quality assurance system through TÜV-Management Service GmbH, South German TÜV corporate group.

Superheated steam boiler (water tube)

Boiler thermal output: 5 - 17 MW

Parameters

Operating pressure (bar): 49

Operating temperature (°C): 450

Feed water temperature (°C): 103

The boiler systems form the heart of every biomass system.

Designed, constructed and tested in accordance with: Designed, constructed and tested in accordance with: EC directive 97/23/EC (Pressure Equipment Directive) whilst employing the following technical specifications: TRD regulations [German technical regulations for steam boilers], AD bulletins [pressure vessels workgroup], EN 287, EN 288, etc, monitoring of the quality assurance system through TÜV-Management Service GmbH, South German TÜV corporate group.

Thermal oil boiler

Boiler thermal output: 5,14 - 12,2 MW

Electricity and heat using an ORC turbine or process heat at high temperature levels.

Parameters

Supply temperatures (°C): 150 to 315

The boiler systems form the heart of every biomass system.

Designed, constructed and tested in accordance with: Designed, constructed and tested in accordance with: EC directive 97/23/EC (Pressure Equipment Directive) whilst employing the following technical specifications: TRD regulations [German technical regulations for steam boilers], AD bulletins [pressure vessels workgroup], EN 287, EN 288, etc, monitoring of the quality assurance system through TÜV-Management Service GmbH, South German TÜV corporate group.
